Special-Purpose Log Semi-Trailer AMKODOR 2310
| MANIPULATOR | |
|---|---|
| Model | AMKODOR KF4556 |
| Maximum boom reach, m, minimum | 5.6 |
| Carrying capacity at maximum reach, kg, maximum | 450 |
| Lifting moment, kNm | 32.9 |
| Swing angle: | |
| - columns in horizontal plane, deg., minimum | 360 |
| - swing mechanism of the working attachment (rotator) | Unlimited |
| Pressure in the hydraulic system, limited by safety hydraulic distributor valve, MPa | 19+1.0 |
| Minimum diameter of captured material, mm | 65 |
| Mass of the hydraulic manipulator, kg | 750 |
| MANIPULATOR | |
|---|---|
| Model | BMF 720 (Estonia) |
| Maximum boom reach, m | 7.2 |
| Lifting moment (gross), kNm | 60 |
| Carrying capacity at maximum reach, kg | 580 |
| Boom slewing angle, deg | 370 |
| MANIPULATOR | |
|---|---|
| Model | PALMS 4,70 (Estonia) |
| Maximum boom reach, m | 7 |
| Lifting moment (gross), kNm | 47 |
| Carrying capacity at maximum reach, kg | 520 |
| Boom slewing angle, deg | 370 |
| OVERALL AND WEIGHT SPECIFICATIONS | |
|---|---|
| Semi-trailer | One-axle, balanced on four pneumatic wheels, frame structure |
| Platform | Welded, with front guard and conics on sides |
| Operating weight (with manipulator, with working attachment and swing mechanism of working attachment), kg, maximum | 4820 |
| Semi-trailer electrical system, V | 12 |
| Length, mm: | |
| - without extension | 7290±100 |
| - with extended extension | 8140±100 |
| Width, mm | 2460±40 |
| Height (over manipulator), mm | 3000±100 |
| Rated semi-trailer carrying capacity, kg, maximim | 10000 |
| Cargo compartment dimensions, minimum: | |
| - length, mm | 5000 |
| - length with extension, mm | 5900 |
| - cross-sectional area, m | 2.4 |
| Length of transported assortments, m | от 2.0 до 6.0 |
| Max. travel speed, km/h: | |
| - on public roads | 30 |
| - on forest roads | 8 |
| Track, mm | 1950±50 |
| Ground clearance, mm | 345 |
| Tires | 20.0/60-22.5 (or 500/55-17) |
| HYDRAULIC SYSTEM |
|---|
| Hydraulic system of working attachment: 1-pump from the rear PTO of the aggregating tool
Swing system: swivel drawbar Service brakes: pad brakes pneumatically driven by an aggregating agent Parking brake system: pad brake mechanisms of the working brake system, mechanically driven |
Forest machines Division
AMKODOR 2310
DESIGNATION
Special-purpose log semi-trailer AMKODOR 2310 is designed for collecting, loading and transporting assortments and other round timber along the territory of cutting areas, skid roads and logging roads to loading areas, as well as for lhandling operations. The semi-trailer is aggregated with forestry tractors of traction class 2.0.
AMKODOR Holding retains the right to change the technical characteristics and design of the machine presented in this prospectus without prior notice.
